Acousto-Optic Anti-Reflection Coatings
- Technology
- Acousto-optics
- Partner
- Isomet
To reduce transmission losses at the entrance and exit surfaces of acousto-optical modulators, Isomet offers a range of standard single wavelength and broadband anti-reflection coatings covering the wavelength ranges from UV to infrared.
In addition, customised broadband and single wavelength coatings are available for all acousto-optical materials.
![Acousto-Optic Anti-Reflection Coatings](https://acalbfi.b-cdn.net/media/jpg/crop-lens-camera-near-abstract-lights-1200x831.jpg)
Range features
A high level overview of what this range offers
- Single wavelength and broadband antireflective coatings
- Standard AR coatings from 235nm to 10.6µm
- Customer-specific AR coatings from 235nm to12µm
- Coatings with reflectivity <0.1 % (per surface) for discrete wavelengths possible
Downloads
for Acousto-Optic Anti-Reflection Coatings
What’s in this range?
All the variants in the range and a comparison of what they offer
Standard AR-coatings / material | UV | VIS | NIR | MIR | IR |
---|---|---|---|---|---|
Quartz | 235 – 250nm | 488 – 532nm | 700-1000nm | – | – |
Quartz | 330 – 360nm | – | 1.06µm | – | – |
Fused silica | 355nm | 532nm | 1.06µm | – | – |
TeO2 | 355nm | 488 – 633nm | 633 – 830nm | – | – |
TeO2 | 360 – 420nm | 532nm | 830 – 1064nm | – | – |
TeO2 | – | – | 1.1 / 1.3 / 1.55µm | – | – |
PbMoO4 | – | 442 – 488nm | 633 – 830nm | – | – |
PbMoO4 | – | 488 – 633nm | 830 – 1064nm | – | – |
PbMoO4 | – | 532nm | 1.1 / 1.3 / 1.55µm | – | – |
Glas | – | 450 – 700nm | 7000 – 1000nm | – | – |
Glas | – | 532nm | 1.06µm | – | – |
Germanium | – | – | – | 2.5 – 5.5µm | 9.4µm |
Germanium | – | – | – | 2.05µm | 10.6µm |
